2016 Ford Transit Towing Capacities

The 2016 Ford Transit is an impressive, full sized van and it had a decent towing capacity attached to it as well, having a maximum capacity of 7,500 pounds! That sounds great but one thing you need to keep in mind is that on the low end, the capacity was only able to pull a maximum weight of 2,900 pounds so quite the range in between!

I lay out everything in this article so you can easily see what 2016 Transit models have the higher towing capacity numbers and which ones fell short. I hope it helps!

Be sure to read the 2016 owner's manual for your transit to get all of the recommended towing information that Ford lays out. I included as much info as I could in this post but it is still advisable to read the manual yourself.

2016 Ford Transit Towing Overview


Overall Towing Capacity:

The 2016 Ford Transit had a towing capacity range of between 2,900-7,500 lbs., according to the 2016 Ford tow charts. This was for the van and wagon models only and did not include the chassis cab models.


3.7L (V6): If your 2016 Transit had the 3.7L engine equipped, then you could expect to see a towing capacity range of between 4,100-6,600 lbs, which is in the middle to higher end of the spectrum compared to the other two engine options.

2016 3.7l Transit Tow Chart

2016 3.7l Transit Tow Chart


3.5L EcoBoost (V6): If you had the 3.5L EcoBoost engine equipped in your 2016 Transit, then you would see a towing capacity range of between 3,800-7,100 lbs., with the low end having a long wheelbase and an extended high roof option, bringing that capacity down a bit because of the extra length and height.

2016 3.5l Transit Tow Chart

2016 3.5l Transit Tow Chart


3.2L Diesel (V8): The 3.2L engine had the highest towing capacity listed in the charts but also the lowest rating. If you had the 3.2L diesel engine equipped, then the towing capacity range was set between 2,900-7,500 lbs.


Again, the lowest specs having a combination of that long wheelbase with either a high roof option or an extended high roof option, bringing those numbers down quite a bit.

2016 3.2l Transit Tow Chart

2016 3.2l Transit Tow Chart

T-150 Models:

The T-150 model Transit's made in 2016 had a towing capacity range of 4,600-7,500 lbs.

T-250 Models:

The T-250 model Transit's made in 2016 had a towing capacity range of 4,200-7,500 lbs.

T-350 Models:

The T-350 model Transit's made in 2016 had a towing capacity range of 2,900-7,100 lbs.

Van Models:

The van models had a towing capacity range of 4,200-7,500 lbs.

Wagon Models:

The van models had a towing capacity range of 2,900-5,100 lbs.

GCWR:

The GCWR for the Transit's made in 2016 had a range of  between 10,800-13,500 lbs.

2016 Ford Transit Towing Charts...

Here are the two towing charts for the 2016 Ford Transit models and the main one that most people will want to take a look at is on the top and it is for the van (cargo model) and wagon (passenger model).

I also included the chassis cab model below that for those of you out there that may want the specs on those models too. These are rarely used by most people though and are usually bought by companies.

Note: Be sure you are looking at the correct towing chart when doing your research, as there are very different specs in each, along with different engine options.

Van/Wagon Chart

2016 Ford Transit Towing Chart

2016 Ford Transit Towing Chart

Cut Away/Chassis Cab Chart

2016 Ford Transit Chassis Cab Towing Chart

2016 Ford Transit Chassis Cab Towing Chart

How To Read The 2016 Ford Transit Charts...

The 2016 Ford Transit Towing charts were quite small in size, overall but there was a lot of information to sift through and for the average person, can come off as very confusing. This is especially true if you have never looked at a towing chart before and have no idea about certain towing related terms like axle ratios.

In this section, I explain what these terms are and where to find them on the 2016 Transit tow chart, so let's get into it.

Note: The charts I used in the below examples are just for representative purposes and should not be used for you 2016 Transit. The charts in the above sections are the correct ones to use as far as towing specs go.

Van VS Wagon: The first two columns in the 2016 Transit tow tables are divided into two separate sections, one for the Transit Van and the other for the Transit Wagon. These are indicated by the red and black outlines in the example image below and to clarify, the van is intended for transporting cargo and the wagon is geared towards transporting passengers.

Van And Wagon Columns

Van And Wagon Columns

T150, T250 and T350 Columns: There are different series Transit models and are labeled as: T-150, T-250 and T-350, much like the Ford trucks (F-150, F-250, F-350, etc.) and these can be found in the 2016 tables towards the top portion of the chart, right below the main "VAN" and "WAGON" columns.

T150 T250 T350 Columns

T150 T250 T350 Columns

Medium (Standard) and Long Wheelbases: There are two different wheelbase options for the '16 Transits' and these are basically just a standard (regular) wheelbase and a long wheelbase. The wheelbase will make a difference of about 100-200 pounds for most models, the shorter wheelbase having the higher capacity numbers.

Transit Wheelbase Data

Transit Wheelbase Data

Roof Heights: The roof height options for the 2016 Ford Transit were similar to other model years and the three main options were the low roof, medium roof and the high roof options. There was also an extended high roof option available for certain models but not as standard as the other three roof height options.

Transit Roof Heights Data

Transit Roof Heights Data

Engine Options: The engine you had equipped in your 2016 Transit is definitely the most important variable that affected your overall towing capacity. The engine options that were available can be found in the left-hand side of the tables, and they make up the major rows in the chart.

Transit Engine Rows

Transit Engine Rows

Axle Ratios: The last piece of information you need to find in the 2016 Transit tow charts are the axle ratios and these can be found just to the right of the engine options, in the same row but form their own rows and make for substantial differences in the towing capacity numbers, if you compare similar models with different axle ratios.

Transit Axle Ratio Column

Transit Axle Ratio Column

Axle Ratios For The 2016 Ford Transits:

You will need to know your axle ratio and plug it into the tow chart in order to get an accurate towing figure but it is not clearly stated anywhere on the vehicle, so you will have to do a little bit of detective work.

The easiest way to figure out your 2016 Transit's axle ratio is to look on the safety certification label, which can be found on the door jamb (driver's side) when the door is open. It will look like the image below.

Transit Safety Certification Label Axle Ratio Area

Transit Safety Certification Label Axle Ratio Area

Once you find that sticker, you need to locate the label that states "AXLE" which is usually located at the bottom of the label towards the center. It will have a two digit figure listed under that section that you need to jot down.

Take the two digit figure you wrote down and plug it into the table I found in the 2016 Ford towing guide. That code will correspond with the axle ratio that was installed on your Transit van.

2015 Transit Axle Codes

Example Of Ford Axle Code

Hitch & Tongue Weight Ratings:

I found this hitch and tongue weight ratings chart in the towing guide and thought it was a nice overview of the maximum trailer weight and tongue weight capacity for the 2016 model Transits.

This is the maximum weight for properly equipped Transits, not all of them, so refer to the tow charts for your correct maximum weight rating.

2016 Transit Hitch Reciever Weight Capacity

Tow Packages & Options:

There wasn't a whole lot of towing equipment options for the 2016 Transits, as you can see by the table below but worth mentioning, nonetheless. It looks as if you can have the trailer wiring hookups, a hitch receiver, an electric brake controller plug in and a tow/haul mode on the console.

So the tow options are basically just the basics when it comes to towing but it did have the tow/haul option which was not an option for the 2015 Transits.

2016 Ford Transit Tow Equipment Options

What Engine Do I Have?

Of course, the most important thing that affected the towing capacity for the 2016 Ford Transit was the engine, as I have stated many times in this article already. Finding out what you have is pretty simple if you pop the hood open and take a peek inside. For those of you who have trouble finding that information in the engine compartment, there is another way to go about it.

You will first need to find your VIN to be able to decipher the data within it. The VIN is located in several places but the three easiest places to find it are on the 1) safety certification label, 2) on your registration card or 3) on your dashboard (on the driver's side).

VIN Decoder Site

Once you have your VIN, plug it into a deciphering website like this one and it will spit out all kinds of very useful information about your Transit. At the top of the results, you should see a column that has the engine equipped and in the case of the below example, this Transit had the 3.7L engine equipped.

Ford Transit Engine Lookup

Van, Wagon and Chassis Cab:

In 2016, Ford made three types of Transit models and these are: the van, the wagon and the chassis cab. These are each different in their own respect and have different tow specs associated with the different models as well.

These three styles of vans are basically designed for different purposes, that is really the difference between the three, which I will explain...

Transit Van: The Transit van is basically a basic vehicle with two front seats and absolutely nothing in the back portion. No seats or windows are present and is better suited for storing things.

The lack of seats makes these ideal for delivery companies and the absence of windows makes it more secure.

Transit Van

Transit Van

Transit Wagon: The wagon model is basically made to transport a large group of people. There are many rows of seating, depending on the model, length, etc. and can seat up to 15 passengers on some of the larger models.

These are usually more popular with companies that run shuttle or transportation services.

Transit Wagon

Transit Wagon

Transit Chassis Cab: The chassis cab models are very minimal, to say the least and are really geared towards companies that want to add a custom rear portion to the body.

These are popular with construction companies because they can customize the back portion with tool boxes and other organizational areas to keep everything clean.

Transit Chassis Cab

Transit Chassis Cab

Roof Heights Explained:

Finding anything on the 2016 Transit's roof height options is nearly impossible for all model years so I had to improvise and put together a little something. I grabbed screenshots of the Transit Van and Wagon roof heights, along with the exterior height specs to give you a better idea of what to expect.

One thing that I did notice is that the low roof (LR) and medium roof (MR) heights were more available for most models, while the high roof (HR) was only available for a couple of different models with specific wheelbase lengths.

2016 Transit Roof Height Data

2016 Transit Van Roof Height Specs

2016 Transit Wagon Roof Height Specs

2016 Transit Wagon Roof Height Specs

Transit Roof Height Options

Transit Roof Height Options

Additional Safety Notes I Found:

I included all of the most important towing related specs for the 2016 Transits, mainly the tow charts and other specs, but I did find other helpful and important information in the owner's manual that is shown in the couple of images below.

There is a lot of other information that you need to know about in all three of the resources I have linked to at the bottom of this article. I recommend doing your own research as well to get familiar with what Ford recommends, your Transit's limits, etc.

Ford Transit Trailer Weight Calculation

Ford Transit Trailer Weight Calculation

Ford Transit High Altitude Weight Compensation Notice

Ford Transit High Altitude Weight Compensation Notice

Ford's Weight Definitions

Ford Transit Maximum Loaded Trailer Weight Definition

Calculating GCWR

Ford Transit Maximum Loaded Trailer Weight Definition

Helpful Links:

I like to include links to all of the resources I used so others can research the information for themselves and for the 2016 Transit's, I gathered all of the information from a couple of different sources. I used Ford's towing guide (2016), the Transit owner's manual and the 2016 Transit brochure for all of the information in this article.
